IPC-410C AND Endurance Series
Artech Panel PCs are touch panel computers integrated into production environments and provide high performance in heavy industrial environment conditions.
- All Winner R18, Quad-Core Processor
- Resistive Flat Touch Screen Technology
- 0-60 Cdeg Working Performance
- Special Locked Slot for Easy Hard Drive Replacement
- 220VAC and 24VDC Options
- Multipurpose Expansion Slot (PCIex, IO, Additional USB - Serial Port etc.)
IP65 Front Panel Protection
10 '' / 15 '' / 17 '' / 21 '' TFT Screen Model Options
Bright and High Contrast TFT LCD Screen
High Precision Flat Touch Screen
Wide Viewing Angle
Sectors
Technical Specifications
System
CPU :
4x ARM Cortex-A17 @ 1.61 GHz
Cache :
N.A.
Memory :
2GB
Video RAM :
N.A.
Control :
N.A.
Watchdog Timer :
Support
Android OS :
Android 8.0
Processor :
4x ARM Cortex-A17 @ 1.61 GHz
I/O
Serial Port :
3 x RS-232 ports (Optional)
Parallel Port :
N.A.
USB Port :
2x USB 2.0
KB / MS :
N.A.
LAN :
1x LAN
Wireless LAN :
802.11 b / g (Optional) / Bluetooth (Optional)
Audio :
Support L/R Phone Jack and 10W / 8Rx2
Expansion Slot :
N.A.
Data Storage
EEMC :
16GB Flash
HDD / Type :
N.A.
SSD :
N.A.
Feed
Power (Max) :
15W
Input :
12VDC
Extra Video Output
Type :
HDMI
Max. Resolution :
1920x1080
LCD Screen
Type and Size :
10.1” / LVDS (16:9 Widescreen)
Max. Resolution :
1280 x 800
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
250cd
Contrast Ratio :
700/1
Viewing Angle :
140°(H),120°(V)
Back Light MTBF :
50,000 Hours
Touch Screen :
10.1" Touch - Capacitive (Optional)
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Stainless Metal Case
Front Frame :
IP65 Aluminium
Weight :
Variable According to Screen Size (1—5 kg)
Dimensions :
(WxHxD) Variable According to Screen Size
Mounting :
Panel and Vesa
Order Code
CPU :
4x ARM Cortex-A17 @ 1.61 GHz
PSU :
DC - 12 VDC
RAM :
R2
Wifi :
Optional
